Power AC100-240V50/60Hz
Ethernet 8* Gigabit PoE Ports|2* Gigabit SFP Ports
Chipset 2 * RTL8367S | RTL8238B
Bandwidth 20Gbps
Pack forward rate 14.88Mpps
MAC address 2K
Jumbo Frame 9216bytes
Transfer mode Store and forward
MTBF 100000 Hours
Network Protocol IEEE802.3 (10Base-T) | IEEE802.3u (100Base-TX) | IEEE802.3ab (1000Base-TX) | IEEE802.3x (Flow control)
PoE Protocol IEEE802.3af(15.4W) | IEEE802.3at(30W)
Network Medium 10Base-T : Cat3, 4, 5 or above UTP(≤100m) | 100Base-TX : Cat5 or above UTP(≤100m) | 1000Base-TX : Cat5 or above UTP(≤100m)
Optical Medium Multimode optical fiber: 50/125, 62.5/125, 100/140um | Single-mode optical fiber: 8/125, 8.7/125, 9/125, 10/125um
LED Indicator PWR (Power)，1-10 Green Light (Link&Data)
1-10 Green Light (Link&Data) On: Link normal | Off: Link blocked | Flashing: Data transmitting
DIP Switch Default: common mode, all interfaces can communicate with each other, the transmission distance is less than 100 meters, the transmission rate is 10/100/1000M adaptive; The port AI mode is disabled Extend: Link extension mode, 7-8 ports force 10M, link 2
Structure Size Product Dimensions: 220*161*44mm | Package Dimensions: 315*215*85mm | Product N.W: 0.88kg | Product G.W: 1.38kg
Power Voltage Input Voltage: AC 100-240 V 50-60Hz
Working Environment Working Temperature: -10~50°C | Storage Temperature: -40~70°C | Working Humidity: 10%~90%, non-condensing | Storage Temperature: 5%~90%, non-condensing
