מק"ט LT15V_EU-IL
4G UE Category 4G LTE Cat. 12 || 4×4 MIMO, 3-CA
Cellualr Module and Working Bands EG120K-EA (on EU Model) | LTE-FDD: B1/3/5/7/8/20/28/32(Optional); | LTE-TDD: B38/40/41/42(Optional)/43(Optional); | Up to 3 × CA: Intra-band and Inter-band; |WCDMA: B1/3/5/8 | EG120K-NA (on US Model) | LTE-FDD: B2/4/5/7/12/13/14/25/26/29/ 30/66/71; |LTE-
4G Speeds Up to 600 Mbps Download | Up to 150 Mbps Upload | LTE-FDD: Max. 600 (DL)/Max. 150 (UL); | LTE-TDD: Max. 430 (DL)/Max. 90 (UL) | DC-HSDPA: Max. 42 Mbps (DL)/ HSUPA: Max. 11.2 Mbps (UL) | WCDMA: Max. 384 Kbps (DL/UL)
Cellular Antennas 4× Internal Antennas | 2× External SMA Connectors (Detachble Antennas not Included)
Cellular Features VoLTE | VoIP | SMS | Band Lock (Band Select) | TTL Settings | Cellular Data Statistics, Data Limit, SMS Alert for Usage | WAN Failover
Wi-Fi Standard Wi-Fi 6 (802.11ax/ac/n/g/b/a)
Wi-Fi Speeds DL/UL MU-MIMO | DL/UL OFDMA | Beamforming | Transmit Power Adjustment
Wi-Fi Features Max 32W
Wi-Fi Encryption WPA-PSK | WPA2-PSK | WPA3-SAE | WPA-PSK/WPS2-PSK | WPS2-PSK/WPA3-SAE
CPU 1.3 GHz Dual-Core Cortex-A53 CPU
ROM 128 MB (1 Gbit) Nand
RAM 256 MB (2 Gbit) DDR3
Ethernet Ports Store-and-forward4× Gigabit Ports
Voice Interfaces 1× RJ11 Port
Buttons WPS Button, Reset Button, Power On/Off
LED Power, Network, Wi-Fi, Phone, WAN/LAN, Celluar Signal Strength
Power DC 12 V ⎓ 1.5 A
VPN VPN Server and Client Options: Zerotier, Wireguard, OpenVPN, IPSec, L2TP, PPTP
DNS Override All Clients' DNS, Rebind Protection, DNS Over TLS, Manual DNS | DNS over TLS | Options: Cloudflare, Google, Quad9
Multi-Mode Router (4G/WAN), WISP (4G as Backup), WISP
Clients Management Internet Block, Internet/Wi-Fi Schedule, VPN Block, Device Rename
Network Management QoS, DDNS, WAN/LAN Switch,
Firewall SPI Firewall, DoS Protection, Block PING
NAT Port Forwarding, Port Triggering, UPnP, DMZ
TTL Extend, Spoof, Custom
IPv6 Relay, Dynamic(SLAAC/DHCPv6), Staic (Fixed IP), Passthrough, MAP-E, DS-Lite
DHCP Server, Client List, Address Reservation
CWMP TR069, TR098, TR111, TR181, Support STUN
Dimension (W×D×H) 190×50×148.8 mm | 7.48×1.97×5.85 inches
Package Content 4G LTE Router | Power Adapter | RJ45 Ethernet Cable | Quick Installation Guide
Environmental Operating Temperature: 0 °C - 40 °C (32 °F - 104 °F) | Operating Humidity: 10% - 90 % non-condensing |Storage Temperature: -30 °C - 70 °C (-22 °F - 158 °F) | Storage Humidity: 5% - 95 % non-condensing
System Windows, MAC OS, NetWare, UNIX, or Linux Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other Javascript-enabled browser If you are using 4G as your internet access, you will need a nano SIM card with an active data subscription, If you are using WAN as
