פרטי המוצר
Projection Technology 3LCD Technology Native Resolution 1280 x 800 (WXGA) Aspect Ratio 16:10 Contrast Ratio 1 16000:1 Brightness 1 3600 ANSI Lumen Brightness (Boost Mode) 3800 ANSI Lumen Lamp 225 W AC (151 W AC Eco Mode) Light Source Life [hrs] 10000 (20000 Eco Mode) Lens F=; 1.7–2.2, f=; 17.4–29 mm Keystone correction +/- 30° manual horizontal / +/- 30° manual vertical Projection Angle [°] 6.6 - 11.1 Projection Factor 1.2 – 2.1 : 1 Projection Distance [m] 0.94 – 11.59 Screen Size (diagonal) [cm] / [inch] Maximum: 762 / 300" Minimum: 76 / 30" Zoom Manual x1.7 Focus Adjustment Manual Supported Resolutions 1920x1200 (Maximum resolution of analog input) Frequency Horizontal: 15–100 kHz (RGB: 24 kHz– 100 kHz) Vertical: 50 – 120 Hz CONNECTIVITY RGB (analog) Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr) Output: 1 x Mini D-sub 15 pin Digital Input: 2 x HDMI™ (Deep Color, Lip sync) Video Input: 1 x RCA Audio Input: 1 x 3.5 mm Stereo Mini Jack 1 x RCA Stereo Output: 1 x 3.5 mm Stereo Mini Jack (variable) Control Input: 1 x D-Sub 9 pin (RS-232) (male) LAN 1 x RJ45 Optional WLAN USB 1 x Type B 1x Type A (USB 2.0 high speed) with 1.5 Power Supply Video Signals NTSC PAL PAL60 SECAM REMOTE CONTROL Remote Control Aspect Ratio Audio Control Auto Adjust AV Mute Digital Zoom Freeze Help Eco Mode ID set Optional Presentation and Mouse Control Picture Adjust Picture Mode Source Select ELECTRICAL Power Supply 100-240 V AC 50 - 60 Hz Power Consumption [W] 293 (High Bright) / 210 (Eco) / 1.5 (Network Stand-by) / 0.5 (Stand-by) MECHANICAL Dimensions (W x H x D) [mm] 345 x 104.6 x 261 (without lens and feet) Weight [kg] 3.2 Fan Noise [dB (A)] 29 / 37 (Eco / Normal) ENVIRONMENTAL CONDITIONS Operating Temperature [°C] 5 to 40 Operating Humidity [%] 20 to 80 Storage Temperature [°C] -10 to 50 Storage Humidity [%] 20 to 80 ERGONOMICS Safety and Ergonomics CE EAC ErP RoHS TUEV Type Approved WEEE Speakers [W] 1 x 16 (mono) ADDITIONAL FEATURES Special Characteristics Auto Eco Mode Auto Power ON/OFF Carbon Savings Meter Colour Management Content Transmission via Network Crestron RoomView DICOM simulation Direct Power-Off Function High Altitude Mode Kensington security slot Keypad Lock Keystone Correction (H=;±30°, V=;±30°) Lens Cover Magnify NaViSet Administrator 2 Off-Timer Optional WLAN OSD with 29 languages Password Security System Quick On/Off RS-232 Control Security Bar USB Display USB Viewer for JPEG Wall Colour Correction GREEN FEATURES Energy Efficiency 75 % AV mute function Auto ECO Mode ECO scheduler Green one touch ECO and AV mute button Intelligent Power Management Longer Light Source Life Reduced power consumption. Only 0.45W stand-by Software scheduling Ecological Materials 100% recyclable packaging Downloadable manuals ECO packaging Ecological Standards ErP compliant RoHs compliant WEEE WARRANTY Projectors 3 years pan-European service Light Source 6 months, max. 1000 hrs SHIPPING CONTENT Shipping Contents IR Remote Control (RD-469E) Mini D-SUB Signal Cable (1.8 m) Quick Setup Guide Security Sticker Users Manual on CD-ROM Utility software OPTIONAL ACCESSORIES Optional Accessories Lamp (NP47LP) Universal Ceiling Mounts (PJ01UCM) Wireless LAN module NP05LM2 (Europe), NP05LM4 (Russia)
